Ringing Generator
Ringing Generator

Ringing Generator

Model NO.
WR40-24S75
Delivery:
EXW,FOB,CIF
Minimum order quantity:
5 pieces
Supply Ability:
5000 pieces / Day
Country of Origin:
Guangzhou
Stock Time:
3-21 Days
Quantity:

40W Ringing Generator Input 18~36Vdc to output 75vac

Why Choose Us


We can produce products in your brand according to your request. If you need more information, pls feel free to contact us.You can get the reply within 24 hours.

Product Description

Typical Features:

Product List

Input Specifications

Input voltage range

Meet Internal Current/Voltage

Nominal24V

1836Vdc

Input Voltage Range2:1

Nominal48V

3672Vdc

RemoteControl (Positive logic control)

Low Level Control

High Level or Suspended

3.5Vdc+Vin

Low Level or Turn off(connect to GND)

≤0.3Vdc

Input under-voltage protection

Lower Input voltage protection, Self-recovery

OutputSpecifications

OutputVoltage accuracy

±5Vac

Line regulation

Nominalload,full voltagerang

±0.5%

Load regulation

20%100% nominal load

±1%

Outputwaveform

Standard Sine Wave

Outputfrequency

25Hz

±3Hz

Total harmonic distortion

Nom±2%

Max±5%

VoltageVoltageadjustment

Not Available

Turn-on delay time

Typical

≤200nS

GeneralSpecifications

TransferEfficiency

Nominal Voltage Range,full load

80%(TYP.)

SwitchingFrequency

200KHz(TYP.)

OperatingTemperature

Free air convection

-25+55

Storage temperature

-40+105

Max case temperature

+90℃

Relative

Humidity

10%90%

CaseMaterial

MetalCase

Isolation Voltage

Input to output500Vdc0.5mA/Min Input to Case 500Vdc0.5mA/Min;

MTBF

2X105Hrs

Hot Sales

Company Profile


Guangzhou Aipu Electron Technology Co., Ltd is a
national high-tech enterprise for power supply solution.
Over more than 15 years, we become one of the most
professional power module manufactures in China.
Specializing in making good quality AC/DC converter,
DC/DC converter from R&D, production and marketing,
our product line have passed CE, RoHS, as well as
multiple management system of ISO9001-2015.

Aipulnion 's quality are widely applied to fields of communication, industrial control, smart home, internet of thing, railway, power industry, charging pile ect.

Our products categories include:
1-700W DC-DC converter,1-200W AC-DC converter and 20-40W Ringing Generator converter.

Certifications


Packing & Shipping


Q1: Are you a factory or trading company?

A1: We are a factory, we can guarantee our price is first-hand, very cheap and competitive.

Q2: How does your factory do regarding quality control?

A2: All the products will be 100% checked before the shipment.

Q3: When can I get the price?

A3:Usually we quote within 24 hours after we get your inquiry.

Q4: How could I get a sample?

A4: If you can not buy our product in your local area, we will ship a sample to you.You will be charged a sample price plus all related shipping costs.Express delivery charge depends on the quantity of the samples.

Q5: What is the price of shipping?

A5: Depending upon the port of delivery, prices varies.
