PCB Mounting 110V/120V/220V/230V/240V AC Input to 24V AC DC Switching Power Supplies 100W
We can produce products in your brand according to your request. If you need more information, pls feel free to contact us.You can get the reply within 24 hours.
Typical Features
Wide Input Voltage Range
Typical Efficiency (Typ. 85%)
Switching Frequency: 65KHz typ
Over Current / Short circuit /Over temperature protection, self-recovery
Input-Output Isolated
PCB Mounting
Metal Case L1
Application Field
WA75-WA100/NA150-220XXXL1 Series-a high efficient compact converter offered by Aipu,
It features universal input voltage range, AC and DC dual-use, low ripple, low temperature rise, low power consumption, high efficiency, high reliability, safer isolation.
The series widely used for industry, office and civil application.
The application circuit in the datasheet is strongly recommended for harsh EMC environment.
| Part no. | Input voltage range | Output voltage/ current | Max. Capacitive Load | Ripple&Noise 20MHz | Efficiency@ Full Load, Nominal Input Voltage (Typical) | |||
| Vo1(V) | Io1(m A) | Vo2 (V) | Io2 (m A) | u F | mVp-p | % | ||
| *WA75-220S05L1 | 100Vac-265Vac/ 140Vdc-380Vdc | 5 | 15000 | - | - | 2000 | 120 | 82 |
| WA75-220S12L1 | 12 | 6250 | 1000 | 120 | 85 | |||
| WA75-220S24L1 | 24 | 3125 | 470 | 120 | 86 | |||
| WA100-220S12L1 | 12 | 8333 | 1000 | 120 | 85 | |||
| WA100-220S24L1 | 24 | 4166 | 470 | 120 | 86 | |||
| NA150-220S12L1 | 165Vac-265Vac/ 200Vdc-380Vdc | 12 | 12500 | 1000 | 120 | 84 | ||
| NA150-220S24L1 | 24 | 6250 | 470 | 120 | 85 | |||
